These are a set of digital files for our Compact Hat Conformer
The WhipperWill Hats compact conformer is designed to capture the shape and size of a customer’s head with far more accuracy than a simple measuring tape. Built with individually adjustable sliders, this tool records the natural oval, long oval, or irregular shape of the head so a hat can be shaped, fitted, or blocked to the customer’s actual head shape.
This flatter, more compact design is easier to store, handle, and ship than a traditional full-size conformer. Each slider can be adjusted independently and locked in place, allowing the captured head shape to be held securely while measurements are transferred to a formillion, hat block, or custom fitting process.
It is also an excellent option for hatters who want a more affordable conformer to send directly to customers who are unable to come in for an in-person fitting. Instead of relying on rough measurements, photos, or guesswork, the customer can use the conformer to capture their actual head shape, then send it back to the hatter for a more accurate custom fit.
Ideal for custom hat makers, western hatters, restoration work, resizing, reshaping, and anyone looking to improve the accuracy of their hat fitting process.
Features:
Captures both head size and head shape
Adjustable individual sliders
Compact segmented design
Designed for approximately 53 cm to 65 cm head sizes
Easier and more affordable to ship than a traditional conformer
Useful for remote customer fittings
Helpful for custom hats, reshaping, resizing, and restoration work
Great companion tool for a formillion or custom hat block setup
Hardware Requirements:
36 × 1/4-20 carriage bolts
36 × 1/4-20 wing nuts
36 × washers, approximately 12 mm outside diameter
18 × M3 screws for assembling the printed ring layers
Optional elastic cord or band for pulling the sliders inward during fitting
Recommended slider locking hardware is 1/4-20 carriage bolts, ideally around 1-1/2 inches long, depending on your print settings and washer/wing nut thickness. For the printed body assembly, M3 screws around 16–18 mm long should work for most builds.
A practical fitting tool for hatters who want a better fit than “close enough,” whether the customer is standing in front of them or halfway across the country. These digital files will allow you to 3d print your own.
